| Socket Head Cap Screw |
|
#0 to 2 |
1936 & 1960
UNC/UNF/BSW |
190,000 <1/2
180,000>1/2 |
B18.3 |
2470 |
A574 |
| Socket Low Head Cap Screw |
|
#8 to 1/2 |
UNC/UNF |
170,000 |
As Per Unbrako Specification |
|
F835 |
| Socket Head Shoulder Screw |
|
1/4 to 2 |
UNC |
HRC 45-53 |
B18.3 |
2470 |
|
| Countersunk Socket Head Screw |
|
#4 to 1 1/2 |
UNC/UNF |
160,000 |
B18.3 |
2470 |
F835 |
| Button Head Socket Screw |
|
#10 to 5/8 |
UNC/UNF |
160,000 |
B18.3 |
2470 |
F835 |
| Flange Button Head Socket Screw |
|
#8 to 1/2 |
UNC/UNF |
As Per Unbrako Specification |
|
2470 |
F835 |
| Knurled Point Socket Set Screw |
|
#4 to 5/8 |
UNC/UNF |
HRC 45-53 |
B18.3 |
2470 |
F912 |
| Plain Point Socket Set Screw |
|
#0 to 5/8 |
UNC/UNF |
HRC 45-53 |
B18.3 |
2470 |
F912 |
| Taper Pressure Plug |
|
#3/4 to 7/8 |
|
|
As Per Unbrako Specification |
|
|
Metric / Inch
